Belt Drive Radial Arm Drill Machine

We are a leading Manufacturer of auto feed radial drilling machine, heavy duty geared radial drilling machine, geared radial drilling machine, double column radial drilling machine, geared drilling machine and fine feed radial drilling machine from Rajkot, India.

Product Details:

Minimum Order Quantity : 1 Unit

Spindle Travel : 250 mm

Spindle Speed : 88-2600 x 8 (RPM x Steps)

Lifting Motor V belt : B-23/B-24

Max and Min Distance Spindle Nose to Base : 850/250 mm

Machine Measurement : 1350 x 850 x 1825 mm (L x B x H)

Work Table Dimenshion : 300 x 300 x 385 mm

Tapping in MS : 20 mm

Drilling in MS : 40 mm

Drilling in CI : 45 mm

Spindle Hole Taper : MT-4

Max and Min Distance Spindle Center to Column : 905/385 mm

Maximium Drilling Radius : 990 mm

Diameter of Column : 170 mm

Available Rough Boring in MS : 60, 75 mm

Available Drill Head Motor : 1.5 HP/960 RPM, 1.5HP/1440 RPM

Available Head Motor V belt : B-46, B-47

Automation Grade : Automatic

Spindle Autofeed Ranges : 0.05 and 0.06 mm/rev

Model : R40-BA

Lifting Motor : 0.5 HP/1440 RPM

Diameter of RAM : 78 mm

Brand : Prakash

With an objective to fulfill the demands of our clients, we are engaged in providing a wide array of Belt Drive Radial Arm Drill Machine.

Features:

2.5 Module Autofeed Gears in R40BA

Taper Cone Mechanism of Autofeed Taper Wedge

Longer Gun Metal Nut for Lifting of Arm

Exclusive Features of R40 Series:

Oil Bath lifting Assembly

Steel worm supported through ball bearings at both sides

Screw supported through taper roller bearings

Wide supports of a column, column bracket & arm

Long bottom for greater rigidity to reduce vibration

Heavy duty column with the Heavily ribbed base plate

Greater Support through closed V - Guideways and I wider drilling head

Better design of arm for higher rigidity and wide support

Standard Accessories:

Motor Pulley

Extra Accessories:

Electrical Motors

"V" Belts

Coolant Pump with Coolant Tank

Drill Chuck & Arbor

Work Table

Tapping Control Panel Board

Keyless Drill Chuck & Arbor

Tapping Attachment (Mechanical)

Extra Long column

Electrical Panel Board in R40BA
